2 Door hardtop rear cap dimensions

[gettk]

Does anyone have the measurements for the 2 door rear cap? i think width is about 70" and the weight 80lbs but dont know the front to back.. Going to see if i can rig up a pulley system on my basketball hoop. if the rear cap is less than 5 feet i should be able to do it with some straps and a manual pulley - no help needed..

Sponsored



[RyanRallyX]

Overall I measured it at 56". Popped off the front panel too, so that includes approx 3 inches of lip at the front for the front panels to seat that u dont see from the outside.



[gettk]

Overall I measured it at 56". Popped off the front panel too, so that includes approx 3 inches of lip at the front for the front panels to seat that u dont see from the outside.

Nice - thank you sir.



[RyanRallyX]

U r welcome. I haven't removed the back yet so not sure if mounting surface sticks out further but looks like u will have some room to play with.



[BDSteelies]

What about height (top to bottom)? I'm looking to rig up a pulley system in the garage as well and wondering much headroom it will take up.



[604Bronco]

I dunno... might be a tight fit. The weight of it might also pose a problem.

I actually think your idea of using a basketball hoop (assuming a heavy duty, in-ground one) is not a bad idea. Curious how this works out for you!



[gettk]

I dunno... might be a tight fit. The weight of it might also pose a problem.

I actually think your idea of using a basketball hoop (assuming a heavy duty, in-ground one) is not a bad idea. Curious how this works out for you!

haha. good or bad I'll follow up. Anchoring it is the key. There is also a post that shows center of gravity from back to front is about 17" in. Makes sense with the weight of the open rear window. And keeping it level through the lift so not to scratch the roll or snap a flange..



[RyanRallyX]

What about height (top to bottom)? I'm looking to rig up a pulley system in the garage as well and wondering much headroom it will take up.

I measure 21.5" ; with top still installed. Width at the base is just shy of 60"
