BDS Suspension

Black Diamond
Member
Squatch Sponsor (Level 3)
First Name
BDS Suspension
Joined
Jul 22, 2021
Threads
2
Messages
13
Reaction score
26
Location
Coldwater, MI
Website
bds-suspension.com
Vehicle(s)
'21 Bronco
Your Bronco Model
Black Diamond
Step your new Bronco up a few notches with these 3-4" lift kits from BDS. Designed to improve suspension travel and allow clearance for larger tires, these kits retain for factory coilover assemblies to maintain ride quality and handling characteristics. As with all BDS products these new kits are backed by Factory Protection Plus for peace of mind out on the trail. Get more from your new Bronco with BDS.



Features/Benefits
  • Maintains vehicle ride and handling performance while improving offroad capability.
  • 2-piece strut spacer design maintains ride quality without overextending suspension during down travel.
  • BDS Upper Control Arms are built from 1.5" OD heavy-wall tubing and including FK uniball joints for maximum durability.
  • Lifts and levels the stance with clearance for oversized wheels/tires.
  • Heavy duty tie rod sleeve reinforces the factory steering.
  • Designed for easy installation and manufactured in the USA.
  • Includes Factory Protection Plus warranty program.
Vehicle Fitment
2-Door Models:
#023411
- 4" Lift Kit w/ 3" Rear (for Base Shock Package)
#023351 – 3.5" Lift Kit w/ 3" Rear (for Badlands models)
#023301 – 3" Lift Kit w/ 2" Rear (for Sasquatch Only)

4-Door Models:
#023410
- 4" Lift Kit w/ 3" Rear (for Base Shock Package)
#023350 - 3.5" Lift Kit w/ 3" Rear (for Badlands models)
#023300 – 3" Lift Kit w/ 2" Rear (for Sasquatch Only)

Final ride height similar between models, lift is based around net lift with factory shock packages. Order based on your stock configuration.

Fitment
2021-2022 Ford Bronco 2Dr (all trim levels)
2021-2022 Ford Bronco 4Dr (all trim levels)

Add-Ons
BDS123302 - Cam Lockout Plates
JKS8300 - Max Tire Clearance Kit
JKS8301 - Front Shock Skids
JKS8308 - Rear Shock Skids (Bilst. shocks)
JKS8309 - Rear Shock Skids (black shocks)

Tires/Wheels
35x12.50 Tires on 17x9 Wheels (5.5" BS)
37x12.50 Tires on 17x9 Wheels (4.5-5.5" BS)
* Installing 37" tires will rub front body mount through wheel travel, trimming necessary (JKS8300 recommended)

Shop Now - BDS.png
Use Code: "JF2022"


Advertisement

Last edited:

SasquatchMansquatch

Base
Well-Known Member
Joined
Aug 31, 2022
Threads
5
Messages
173
Reaction score
105
Location
California
Vehicle(s)
4 door basquatch
Your Bronco Model
Base
Looks interesting. Any reviews or testimonials?


rtaylor

Badlands
Well-Known Member
First Name
R
Joined
Jul 13, 2020
Threads
10
Messages
1,039
Reaction score
2,354
Location
ID
Vehicle(s)
19Raptor, 22Bronco
Your Bronco Model
Badlands
Clubs

Looks interesting. Any reviews or testimonials?
Just search for Maxlider lift (early release of this kit). They've been available for over a year. I think the only difference is the addition of the JKS sleeve, and that has been available for a while too. I am using the BDS UCA with Icon coilovers, and it has enough range (but less margin than factory). The only downside to the sleeve is that your alignment shop will hate it (must use pliers instead of wrench to adjust).


Gene Dios

Badlands
Well-Known Member
Joined
Jul 27, 2020
Threads
8
Messages
274
Reaction score
806
Location
Atlanta
Vehicle(s)
Ford Explorer
Your Bronco Model
Badlands
Clubs

Seems like there's way too much focus on these tie rod bandaids and not nearly enough on the steering rack of these things, which are apparently made from paper mache


Advertisement

Hkak45

Black Diamond
Well-Known Member
First Name
Harold K
Joined
Aug 6, 2020
Threads
14
Messages
1,082
Reaction score
2,478
Location
Illinois
Vehicle(s)
21 Bronco Black Diamond
Your Bronco Model
Black Diamond
Clubs

Honest question, other than "just for looks", why would you want to go 3"-4" Spacer on the bronco? Would this not completely ruin the off road ability and limit the flex of the suspension vs just pony up the money and do a suspension lift? I'm asking because these pucks seem like they would hinder the off road ability but I may also be completely wrong so looking for someone to chime in.


dangerfoot

Wildtrak
Well-Known Member
First Name
Justin
Joined
Aug 22, 2022
Threads
1
Messages
78
Reaction score
41
Location
Austin TX
Website
www.dangerfoot.com
Vehicle(s)
White Wildtrak 4dr
Your Bronco Model
Wildtrak
Clubs

Honest question, other than "just for looks", why would you want to go 3"-4" Spacer on the bronco? Would this not completely ruin the off road ability and limit the flex of the suspension vs just pony up the money and do a suspension lift? I'm asking because these pucks seem like they would hinder the off road ability but I may also be completely wrong so looking for someone to chime in.
Spacer lifts are the cheapest way to bring lift and don't provide any additional performance.

I wouldn't put one on (have done this in the past, I've learned from my experiences)...but for many, they'll be a "good" solution.


badbronc4x4

Badlands
Active Member
First Name
Cory
Joined
Aug 18, 2022
Threads
5
Messages
31
Reaction score
82
Location
Scottsdale, AZ
Vehicle(s)
2022 Ford Bronco Badlands Sasquatch
Your Bronco Model
Badlands
Step your new Bronco up a few notches with these 3-4" lift kits from BDS. Designed to improve suspension travel and allow clearance for larger tires, these kits retain for factory coilover assemblies to maintain ride quality and handling characteristics. As with all BDS products these new kits are backed by Factory Protection Plus for peace of mind out on the trail. Get more from your new Bronco with BDS.

Features/Benefits
  • Maintains vehicle ride and handling performance while improving offroad capability.
  • 2-piece strut spacer design maintains ride quality without overextending suspension during down travel.
  • BDS Upper Control Arms are built from 1.5" OD heavy-wall tubing and including FK uniball joints for maximum durability.
  • Lifts and levels the stance with clearance for oversized wheels/tires.
  • Heavy duty tie rod sleeve reinforces the factory steering.
  • Designed for easy installation and manufactured in the USA.
  • Includes Factory Protection Plus warranty program.

4-Door Models:
#023410
- 4" Lift Kit w/ 3" Rear (for Base Shock Package)
#023350 - 3.5" Lift Kit w/ 3" Rear (for Badlands models)
Do you guys have a Differential Drop piece for the Badland Model's? I would assume you have something to retain more travel and keeping the CV Axels from having more wear and etc. Also, do you plan on making Long Travel Knuckles?

OP
OP
BDS Suspension

BDS Suspension

Black Diamond
Member
Squatch Sponsor (Level 3)
First Name
BDS Suspension
Joined
Jul 22, 2021
Threads
2
Messages
13
Reaction score
26
Location
Coldwater, MI
Website
bds-suspension.com
Vehicle(s)
'21 Bronco
Your Bronco Model
Black Diamond
Do you guys have a Differential Drop piece for the Badland Model's? I would assume you have something to retain more travel and keeping the CV Axels from having more wear and etc. Also, do you plan on making Long Travel Knuckles?
We don't currently have a diff drop yet... YET

We have several Bronco products in development right now. I can say (but shouldn't) that we currently have a Bronco on a 6" lift, rolling on 40's that's in testing right now. Along with that comes all the ancillary products you would expect, like diff drops. As far as axles go, RCV has/is developing Bronco specific axle needs.


Advertisement
OP
OP
BDS Suspension

BDS Suspension

Black Diamond
Member
Squatch Sponsor (Level 3)
First Name
BDS Suspension
Joined
Jul 22, 2021
Threads
2
Messages
13
Reaction score
26
Location
Coldwater, MI
Website
bds-suspension.com
Vehicle(s)
'21 Bronco
Your Bronco Model
Black Diamond
Honest question, other than "just for looks", why would you want to go 3"-4" Spacer on the bronco? Would this not completely ruin the off road ability and limit the flex of the suspension vs just pony up the money and do a suspension lift? I'm asking because these pucks seem like they would hinder the off road ability but I may also be completely wrong so looking for someone to chime in.
Currently, it's the limitation of coilover products for the Bronco. Some companies have gone to marketing with solutions. FOX is taking the development of the Bronco coilover very seriously, especially with their OE partnership with Ford, so we're a little slower to go to market with our coilover. HOWEVER, spacer kits paired with a UCA provide suspension correction so that you can retain/gain suspension articulation that you would expect from a lift kit. Spacer kits alone only add height, but do not correct suspension geometry.

OP
OP
BDS Suspension

BDS Suspension

Black Diamond
Member
Squatch Sponsor (Level 3)
First Name
BDS Suspension
Joined
Jul 22, 2021
Threads
2
Messages
13
Reaction score
26
Location
Coldwater, MI
Website
bds-suspension.com
Vehicle(s)
'21 Bronco
Your Bronco Model
Black Diamond
Seems like there's way too much focus on these tie rod bandaids and not nearly enough on the steering rack of these things, which are apparently made from paper mache
Give it a year. The market will be saturated with aftermarket solutions.


Slick85

Big Bend
Well-Known Member
First Name
Richard
Joined
Jan 30, 2022
Threads
16
Messages
196
Reaction score
129
Location
Austin, TX
Vehicle(s)
Bronco
Your Bronco Model
Big Bend
Clubs

Give it a year. The market will be saturated with aftermarket solutions.
If I'm doing a 4in lift with 37s just for looks and plan to do very minor off-roading, would I need to upgrade the tie-rods and steering rack? Or should I just stick with 2in lift and 35s for a mall crawler?


Jvmulligan

Outer Banks
Member
First Name
Jack
Joined
Jan 23, 2022
Threads
1
Messages
10
Reaction score
6
Location
Phoenix
Vehicle(s)
2022 4 door Outer Banks and 2002 Jeep TJ Wrangler
Your Bronco Model
Outer Banks
Clubs

I am also looking at lifting my stock outer banks. The low price of the 2 inch level kits are compelling. Off roading is light, this would be just for looks. But, as a non-diy guy, it seems once a technician has taken the suspension apart doing spacers vs something with the coils would be a similar install cost. Incremental cost being just the difference between a true coil over lift and spacers. Am I right on this?
