Antenna Mount Help

[Eldritch Himbo]

Howdy Y'all, I bought the Trailrax hood strut mount so I could mount an antenna to to the front of my Bronco. I just want the antenna for aesthetic reasons, I am not planning on hooking it up to an actual radio. Could someone give me some advice on what hardware I need to mount the antenna to the bracket?

Trailrax hood strut mount (https://www.trailrax.com/products/ford-bronco-trail-sight-accessory-mount)
Antenna (https://www.amazon.com/dp/B097R8TLLV?psc=1&ref=ppx_yo2ov_dt_b_product_details )

Sponsored



[JonathanDuong]

Washer, nut, and bolt? Doesn't look car wash friendly...



[Moto26]

Seriously?



[Eldritch Himbo]

Washer, nut, and bolt? Doesn't look car wash friendly...

Seriously?

Yes.



[Eldritch Himbo]

Washer, nut, and bolt? Doesn't look car wash friendly...

This is not helpful



[Moto26]

You could use this one. It’s self-adhesive…



[BlazinGTO]

This is not helpful

That's very close to what you need.

The bracket came with mounting hardware. So that's all set.

The antenna is UHF female. Which is 5/8-24 I think. That screw is too big to fit through the bracket probably. So you need hardware to screw into the antenna and has a male threaded end that fits through the bracket.

Now just a washer and nut.


Any maybe run a fake wire too, to finish the look.



[Vinny6G]

I'm guessing just a SO-239 connector based on that antenna? But that hole in the bracket looks too small to accommodate that. Unless you drill it out, use the SO-239 and then cap it with a washer and a nut.



[Eldritch Himbo]

That's very close to what you need.

The bracket came with mounting hardware. So that's all set.

The antenna is UHF female. Which is 5/8-24 I think. That screw is too big to fit through the bracket probably. So you need hardware to screw into the antenna and has a male threaded end that fits through the bracket.

Now just a washer and nut.


Any maybe run a fake wire too, to finish the look.

Hey thank you so much for the help reply man, this definitely gives me idea what I need to do and I appreciate it



[Eldritch Himbo]

I'm guessing just a SO-239 connector based on that antenna? But that hole in the bracket looks too small to accommodate that. Unless you drill it out, use the SO-239 and then cap it with a washer and a nut.

Thanks so much for the reply, I made it and I’m drawing I’m not quite sure. I appreciate you helping me out, thank you!



[Sparkherd]

I just want the antenna for aesthetic reasons, I am not planning on hooking it up to an actual radio.

WHAT?!?



[JMB]

Howdy Y'all, I bought the Trailrax hood strut mount so I could mount an antenna to to the front of my Bronco. I just want the antenna for aesthetic reasons, I am not planning on hooking it up to an actual radio. Could someone give me some advice on what hardware I need to mount the antenna to the bracket?

Trailrax hood strut mount (https://www.trailrax.com/products/ford-bronco-trail-sight-accessory-mount)
Antenna (https://www.amazon.com/dp/B097R8TLLV?psc=1&ref=ppx_yo2ov_dt_b_product_details )

Every antenna is gonna need a radio.



[NewBroncoOwner]

This is not helpful

It looks like you are fairly new here on the forum. You will need some thick skin and a sense of humor to continue.



[Sparkherd]

Every antenna is gonna need a radio.

Wut up Rover?



[BottleShark]

Yes.

You should also get Raptor lights and 13" wide / 22" tires.......
