Edit this is my experience for my vehicle I cannot guarantee results for your vehicle proceed at your own risk!
Ok first attempt at trying this so I hope you can follow along.

I set out to put the color change ambient lighting in my bronco but did not want an aftermarket setup(yes aftermarket would have cheaper by far)

so I started in forscan in the plain English apim. By changing the ambient lighting type to pantatone and write that gets you the color selection screen

I also found a thread on an f150 thread that said to change a line in the as built apim as just changing the plain English does not let you actually use the options on the color change screen.
Ford Bronco Color changing ambient lighting using Ford OEM parts BF86B747-F794-4BDD-BE1E-BE277EC73DE2



That seemed to do the trick so I then ordered some led’s from ford. Here is the list I found and what I ordered.
Ford Bronco Color changing ambient lighting using Ford OEM parts FFC5FA45-6824-4131-A37C-6B552BE360B6

After a month the first two lights showed up. The drivers side was a simple swap with just having to shave off two guide nubs so it would plug in.
Ford Bronco Color changing ambient lighting using Ford OEM parts 41FF3632-F1C9-4417-B19A-BC58AF7D3578

The passenger side factory light has a female end vs the male. I did not get pictures but I swapped the ends so I could plug it in. In the parts list the passenger footwell light may have the correct end but I ordered these particular lights because thewere the identical size/shape for our factory holders.
Ford Bronco Color changing ambient lighting using Ford OEM parts 4341370C-AC54-42F7-AEFE-824BAA21DE33

Once this all worked one of my sons asked are you going to put them back here for us in the back seat too. Well then I looked under the seats.
Ford Bronco Color changing ambient lighting using Ford OEM parts 898697FB-1C56-4693-98A1-8509A3C2C2B2

I’ll be darned if ford didn’t put a rectangle hole the size of the ambient lights built into the plastic under the seat.
Ford Bronco Color changing ambient lighting using Ford OEM parts F3466554-1BEB-486B-9360-46F486383628

I then remembered a post on the ford truck enthusiast forum of a member making and selling ambient light harnesses for the superduty and offering cup holder setups as well. I got in touch with @JHForman812 to make me a harness for the lights under the seats and the cup holders.

Ford Bronco Color changing ambient lighting using Ford OEM parts 08A74BCF-9916-4EE0-A5E5-26A7B2D73770

After much discussion and measurements he found a cup holder assy that he thought would work.
Ford Bronco Color changing ambient lighting using Ford OEM parts 7F9F6792-FCB8-4F35-85AB-AAA4D4EBD4C8

This part of the project is not for the faint of heart. The cup holder is not a drop in replacement. Many things had to be trimmed on both the underside of the console and on the new cup holder. All 6 mounting posts on the console had to be shortened by 1/4” or more but it was a slow trim test process. I did not get get pics of my cutting the console up. It was tedious to get it to look good. Maybe an hour and a half of work. The cup holder comes with everything except the led’s. The harness guy supplied them as well so I do not have part numbers for the leds themselves. After I received everything it was just a matter of plugging the harness into to where the drivers side light is connected. This harnes extends out from the driver side ambient light connection. Then removing the console and running the wire extensions from the drivers side ambient light under the dash thru the console and then down under the seats. The under seat leds will fit in the rectangle holes without any trimming and if you press firmly will stay. If you want a completely flush fit under the seats minor trimming is needed to the seat plastic. Then you have ambient lights that change color in five locations.
Ford Bronco Color changing ambient lighting using Ford OEM parts C71CB4F5-D015-40C7-8832-EF0135D1C238
Ford Bronco Color changing ambient lighting using Ford OEM parts D52B4383-531F-4DC0-B650-DB0A3166AEBB
Ford Bronco Color changing ambient lighting using Ford OEM parts 1D961256-1475-418F-BE69-0B79385735E5
Ford Bronco Color changing ambient lighting using Ford OEM parts E381F667-13E3-4508-8451-385ED4DA3741
Ford Bronco Color changing ambient lighting using Ford OEM parts F69D4C8D-39E0-47C5-937B-9254C9CD552A

because I added the under seat lights and cupholder lights I’m in this project for near $300. I ended up ordering two seats of the under seat lights. I don’t see a difference from left to right so a guy could order 4 of one and be okay. But it’s all factory led controlled through sync and looks factory. If a guy got the connectors and made his own harness he could probably trim costs down quite a bit.

Edit I forgot a couple pics drivers side led and connector
