Confirmed by Ford / BN today:

All 2021 Ford Bronco models will be flat towing capable, regardless of which available transfer case is equipped. Both the standard 4×4 and Advanced 4×4 transfer cases can be towed with all four wheels on the ground. The capability is noted in the Bronco build and price tool under the details for both the 4×4 systems and Bronco Nation has confirmed with Ford that this is correct.

Looking at the current Ranger owner’s manual can give us some clues for what will be required for Broncos to be towed in this configuration. A combination of selecting a setting on the Bronco’s informational display, selecting 2H on the GOAT dial, and shifting the transmission into neutral will probably be required to flat tow the Bronco without damaging the transfer case. Also, typical tips and tricks with flat towing will probably apply. Make sure that you set your climate control system to a recirculating air mode to keep the exhaust fumes out.

https://community.thebronconation.com/forums/threads/an-update-on-flat-towing-a-bronco.2853/
Advertisement



TripleB

Base
Well-Known Member
Joined
Jul 14, 2020
Messages
739
Reaction score
1,287
Location
Georgia
Vehicle(s)
2019 GMC AT4 6.2L, 2021 Ford Bronco Base Sas 2.7L
Bronco
Base
Will the speedo roll while towed?


SHLYGRR

Badlands
Well-Known Member
First Name
Nick
Joined
Jul 20, 2020
Messages
436
Reaction score
2,156
Location
California
Vehicle(s)
Hyundai Elantra GT Sport
Bronco
Badlands
Clubs

How many Broncos can I daisy-chain tow haha?


Rick Astley

Badlands
Well-Known Member
First Name
Rick
Joined
Jul 24, 2020
Messages
3,469
Reaction score
13,344
Location
Seattle, WA
Vehicle(s)
2-stroke unicycle
Bronco
Badlands
And remove both driveshafts.
It's been incredibly rare to have issues, however, driveshaft phasing has been a problem with Ranger. Ford's miracle "cure-all" for out-of-balance driveshafts has been the lackluster effort of gluing metal in places or drilling out material. Certainly they can hold their parts supplier to greater standards than what was done in the 1960's when tolerances were generous.

Will the speedo roll while towed?
Reports from the Ranger group indicate that when you engage the flat-tow via their lengthy process, it will disable the electronic O-do. Not great for tracking vehicle mileage, but the lesser of two evils.


vrewald14

Badlands
Well-Known Member
First Name
Vince
Joined
Jul 17, 2020
Messages
352
Reaction score
1,993
Location
Iowa
Vehicle(s)
03 Ford Excursion, 79 Ford Bronco, 04 Toyota Camry
Bronco
Badlands

Felix808

Badlands
Well-Known Member
Joined
Jul 19, 2020
Messages
1,256
Reaction score
2,558
Location
SRV CA
Vehicle(s)
Waiting for 4-door Badlands Bronco
Bronco
Badlands
Clubs

A combination of selecting a setting on the Bronco’s informational display, selecting 2H on the GOAT dial, and shifting the transmission into neutral will probably be required to flat tow the Bronco without damaging the transfer case. Also, typical tips and tricks with flat towing will probably apply. Make sure that you set your climate control system to a recirculating air mode to keep the exhaust fumes out.
It's not the transfer case that's at risk of damage, it's the auto transmission that overheats due to no fluid pumping to keep things cool.


Parker

Black Diamond
Well-Known Member
Joined
Jul 25, 2020
Messages
313
Reaction score
313
Location
PA / CA /AZ
Vehicle(s)
Gr Che Overland, Corvette, Tahoe, 46 Chevy 2ton
Bronco
Black Diamond
Best thing to do when flat towing is to disconnect the battery and use a light bar that feeds off the towing vehicle.
For brakes use "Ready-Brute" mechanical system.
Electrical systems today are too complex to risk mixing two together.


CaseyH

Badlands
Active Member
First Name
Casey
Joined
Sep 25, 2020
Messages
26
Reaction score
64
Location
California
Vehicle(s)
M4, Camaro, Ram 1500
Bronco
Badlands
Clubs

Will the speedo roll while towed?
In most all vehicles these days with all electric speedos, the mileage doesn't roll forward when the vehicle is being flat towed. (Can't confirm it will be the case with the Bronco, but it is the norm)

In the old days when it was a mechanical speedo, the mileage did roll forward.
