Got stuck on breakover angle and now multiple errors

BAUS67

Base
Well-Known Member
First Name
redneck
Joined
Jan 3, 2020
Threads
22
Messages
4,521
Reaction score
13,086
Location
Central PA
Vehicle(s)
88 5.0 LX, 08 F-150 Stepside, 22 Expl Timberline
Your Bronco Model
Base
Clubs

Yes that it is. When posting I could only come up with high-sided but knew it was the wrong term.


It is also referred to as being "turtled".

Sponsored



swooshdave

Badlands
Well-Known Member
Joined
Dec 15, 2020
Threads
68
Messages
4,275
Reaction score
7,799
Location
Portland, Oregon
Vehicle(s)
Mustang
Your Bronco Model
Badlands
Clubs

I was going up a 22 degree sand pile with the intent to stop before cresting over. At the top I went to stop but slid over a bit in the snow and got stuck with all the tires spinning in the air after.

As soon as the bronco got stuck the errors came on the dash. I was going pretty slow when it happened. Traction boards were no help but I got out with a single soft tug from a F-150.

ABS and AdvanceTrac lights are on. It still lets me turn AdvanceTrac on and off. ABS, AdvanceTrac, collision, and side traffic alert are all errors I can remember. While idling they will re-alert every 20 seconds or so. On the few mile drive home "Service Vehicle Soon" came up and feels like it's shifting slightly rough. If I try to use the swaybar disconnect, I get an error and it does not disconnect.

The truck is sitting at home while I'm at work today. The battery is disconnected. Underneath the truck it looks fine. The sand is all on the skid that protects the gas tank. No sand underneath anywhere forward of that.

While I was stuck, I noticed that one rear tire was not spinning even with the dif locked. All other three tires were spinning. The power distribution screen shows nothing even when the tires were spinning.

Going to reconnect the battery when I get home. Maybe bring it to the carwash and get some sand out? Anything I could look for underneath? Sounds like some kind of electrical/electronic problem. Nothing was rough on the truck with the stuck or unstuck process. Will be making an appointment with the dealer of course.
Next time put it in one of the GOAT modes and see if it freaks out.


Dantastic

Outer Banks
Well-Known Member
First Name
Daniel
Joined
Sep 12, 2022
Threads
16
Messages
489
Reaction score
1,707
Location
Lake Saint Louis, MO
Website
www.youtube.com
Vehicle(s)
OBX Sas Bronco, Mazda CX-5
Your Bronco Model
Outer Banks
Clubs

It is also referred to as being "turtled".

But that can also mean stuck on your back ... Which if your bronco is that kind of turtled ... you got a lot more issues than a few codes.


popo_patty

Big Bend
Well-Known Member
First Name
Caleb
Joined
Nov 14, 2021
Threads
43
Messages
910
Reaction score
2,646
Location
Sacramento
Vehicle(s)
2021 Bronco/1996 Jeep XJ/1957 FC-150
Your Bronco Model
Big Bend
Clubs

You have a wiring harness running along your frame rails on the driver side. Can’t remember if there is one on the passenger side too. Either way they have a big connection point somewhere below the front doors on the frame. Check it and see if if those got disconnected somehow


Sponsored

JediMcMuffin

Badlands
Well-Known Member
First Name
Tommy
Joined
Jun 15, 2021
Threads
30
Messages
1,730
Reaction score
3,135
Location
San Diego
Vehicle(s)
2021 Bronco Badlands
Your Bronco Model
Badlands
Clubs

I was going up a 22 degree sand pile with the intent to stop before cresting over. At the top I went to stop but slid over a bit in the snow and got stuck with all the tires spinning in the air after.

As soon as the bronco got stuck the errors came on the dash. I was going pretty slow when it happened. Traction boards were no help but I got out with a single soft tug from a F-150.

ABS and AdvanceTrac lights are on. It still lets me turn AdvanceTrac on and off. ABS, AdvanceTrac, collision, and side traffic alert are all errors I can remember. While idling they will re-alert every 20 seconds or so. On the few mile drive home "Service Vehicle Soon" came up and feels like it's shifting slightly rough. If I try to use the swaybar disconnect, I get an error and it does not disconnect.

The truck is sitting at home while I'm at work today. The battery is disconnected. Underneath the truck it looks fine. The sand is all on the skid that protects the gas tank. No sand underneath anywhere forward of that.

While I was stuck, I noticed that one rear tire was not spinning even with the dif locked. All other three tires were spinning. The power distribution screen shows nothing even when the tires were spinning.

Going to reconnect the battery when I get home. Maybe bring it to the carwash and get some sand out? Anything I could look for underneath? Sounds like some kind of electrical/electronic problem. Nothing was rough on the truck with the stuck or unstuck process. Will be making an appointment with the dealer of course.
I had this same series of lights come on very early into ownership. I resolved it myself by tightening up every ground point in the engine bay and the two bolts inside the engine bay fuse box. It did not return. Recently I had an issue where the vehicle would not even attempt to start. Part of that was a failing battery that didn't really show symptoms of failing. This also exposed some issues with the AWD module which kept failing and leaving me without transfer case control. That module and the battery were replaced and I'm whole again, all with less than 1000 miles of warranty left. :O

OP
OP
BlazinGTO

BlazinGTO

Badlands
Well-Known Member
First Name
Dustin
Joined
Dec 7, 2020
Threads
7
Messages
573
Reaction score
1,020
Location
MA
Vehicle(s)
2004 GTO M6 2004 Escape
Your Bronco Model
Badlands
I'm headed home in about an hour.

I've received some advice including checking the wheel speed sensors. I also found a post where someone had debris on their sensor and had basically all the same faults. Park aid, cross traffic, pre-collision assist, service advancetrac, abs fault. They faults went away after cleaning it. I'll be checking that first and I'm hoping one is just covered with debris and not actually damaged.

I'm crossing my fingers I can get this resolved on my own and be able to make the drive to VT and see the solar eclipse using my own vehicle on Monday

OP
OP
BlazinGTO

BlazinGTO

Badlands
Well-Known Member
First Name
Dustin
Joined
Dec 7, 2020
Threads
7
Messages
573
Reaction score
1,020
Location
MA
Vehicle(s)
2004 GTO M6 2004 Escape
Your Bronco Model
Badlands
I had this same series of lights come on very early into ownership. I resolved it myself by tightening up every ground point in the engine bay and the two bolts inside the engine bay fuse box. It did not return. Recently I had an issue where the vehicle would not even attempt to start. Part of that was a failing battery that didn't really show symptoms of failing. This also exposed some issues with the AWD module which kept failing and leaving me without transfer case control. That module and the battery were replaced and I'm whole again, all with less than 1000 miles of warranty left. :O
Thank you, I'll take a look at this too.


thenewjs

Raptor
Well-Known Member
First Name
Archie
Joined
Jul 14, 2020
Threads
1
Messages
941
Reaction score
1,293
Location
200011
Vehicle(s)
Braptor
Your Bronco Model
Raptor
Clubs

Same happen to a guy, in our off roading group. He limp off the trail and once it got up to a certain MPH on the way home it corrected itself.


Fordified1

Black Diamond
Well-Known Member
First Name
Bob
Joined
Nov 1, 2023
Threads
13
Messages
1,196
Reaction score
2,829
Location
Mid South Texas
Vehicle(s)
‘15 Mustang ecoboost, 4wd Excursion, ‘69 Mach 1
Your Bronco Model
Black Diamond
Clubs

Technology is cool…. Until it isn’t.

Someone needs to invent a nanny override program and push button lol.


Sponsored

Fordified1

Black Diamond
Well-Known Member
First Name
Bob
Joined
Nov 1, 2023
Threads
13
Messages
1,196
Reaction score
2,829
Location
Mid South Texas
Vehicle(s)
‘15 Mustang ecoboost, 4wd Excursion, ‘69 Mach 1
Your Bronco Model
Black Diamond
Clubs

I had this same series of lights come on very early into ownership. I resolved it myself by tightening up every ground point in the engine bay and the two bolts inside the engine bay fuse box. It did not return. Recently I had an issue where the vehicle would not even attempt to start. Part of that was a failing battery that didn't really show symptoms of failing. This also exposed some issues with the AWD module which kept failing and leaving me without transfer case control. That module and the battery were replaced and I'm whole again, all with less than 1000 miles of warranty left. :O
Thanks for this, I had read in another thread that tightening all the grounds was one of the first things to do when one gets their new Bronco. I had forgotten about that.


nipeej

Badlands
Member
First Name
Rick
Joined
Jun 16, 2023
Threads
8
Messages
20
Reaction score
7
Location
Dewey, Arizona
Vehicle(s)
Honda, Toyota, Ford
Your Bronco Model
Badlands
I know its fun to go up a steep incline and then back down. If you come to a berm that you must go over you need to hit it at an angle, one tire cresting at a time so you have at least one or two tires still on the ground. FYI


BroncoAZ

Badlands
Well-Known Member
First Name
Mitch
Joined
Mar 11, 2021
Threads
26
Messages
2,328
Reaction score
4,044
Location
Cape Cod, MA, formerly Flagstaff, AZ
Vehicle(s)
2021 2 Door Badlands manual, 2021 Tacoma TRD OR
Your Bronco Model
Badlands
This particular time, no. I go to a washed out dirt road that is closed to traffic but I can make it down to a trailhead I use. It's fairly mild and I only use 4A or 2wd.

This is the sand I was on. This is from an earlier time this week. It's used to block access to the road and my son likes when we pull up onto it. After, we back down and go around.
Not to be “that guy”, but there is a Road Closed sign and a pile of what looks more like gravel or asphalt millings than sand blocking the road. Perhaps someone should not give our community a bloody nose by not venturing into closed areas. I may get flamed for this comment, but when I lived out west it was a constant battle to keep trails open and people ignoring the closed signs usually resulted in stricter enforcement and additional closures.

Also, four door problems. The extended wheelbase of the lifted Ford Flex doesn’t help with break over angle.
