MIC Top 1.0 inside construction & material (cross section) - pics

[aj_benedetto]

Hello! My store recently replaced a MIC 1.0 top for one of our customers, and part of the replacement process required us to cut up the old top panels. Would anyone be interested in seeing the inside of the MIC top?


Edit: Below are some pictures that I took of the MIC 1.0. After inspecting the top and seeing just how thin that outer shell is, I can see why the honeycomb structure of the top was showing through when exposed to extreme heat/moisture.

Sponsored



[NotGuilty]

Ford Motor Company right now.



[jehines3]

My understanding of all things internet. Without pics it didn’t happen.



[Lucky Nut]

I mean, sure why not.

We know what's in there. You can pretty much see it from the outside.



[aj_benedetto]

Pics are up!



[Blue's B6G]

Also, can you tell any difference between MIC 1.0 and MIC 2.0?



[GT500]

If this bothers you then you never want to visit an assembly plant to watch how your vehicle goes together.



[aj_benedetto]

Also, can you tell any difference between MIC 1.0 and MIC 2.0?

They look virtually identical outside of the rolled edges.



[kodiakisland]

Pretty sure that’s the same cellulose they put in shredded cheese.



[Bronco21fan]

Hello! My store recently replaced a MIC 1.0 top for one of our customers, and part of the replacement process required us to cut up the old top panels. Would anyone be interested in seeing the inside of the MIC top?


Edit: Below are some pictures that I took of the MIC 1.0. After inspecting the top and seeing just how thin that outer shell is, I can see why the honeycomb structure of the top was showing through when exposed to extreme heat/moisture.

View attachment 200196
View attachment 200197
View attachment 200198
View attachment 200199
View attachment 200200

Why the fuck would they make a top out of cardboard couldn’t they just use like all plastic or even fiberglass



[Bronco21fan]

Well ford can say they made the worst removable top in the history of our sport



[Boxer4]

Looks like Nomex or fiberglass honeycomb.
@aj_benedetto did they replace the side glass and reuse the rear glass ?



[Dragline]

Why the fuck would they make a top out of cardboard couldn’t they just use like all plastic or even fiberglass

Weight. The core is essentially to give distance between the outer shell. The more separation between the top and bottom the greater the bending load they can carry.



[j_marinelli]

They should of just used Amazon Prime boxes. Tops would of had a faster turnaround time doing that.



[Ksjrb03]

Looks like Nomex or fiberglass honeycomb.
@aj_benedetto did they replace the side glass and reuse the rear glass ?

All glass is reused from MIC 1.0 on the 2.0 replacement.
