***Updated December 29th, 2023***
Via BN:
Components
Engine Oil
Capacity (including the oil filter) for the EcoBoost engines:
Coolant
Capacity for the cooling systems:
Fuel Tank Capacity
The two- and four-door models’ tanks hold:
Air Conditioning
All Broncos’ AC systems hold 19.4 ounces of refrigerant.
Washer Fluid
The manual doesn’t say how much the washer fluid reservoir holds, just to fill as needed.
Transmission Fluid
The fluid capacity (approximate dry fill. Actual amount could vary during fluid changes):
Brake Fluid
Capacity: the clutch and brake systems’ quantity is listed as “Fill as required.”
Transfer Case Fluid
The T-case holds:
Axle Fluid
Front axle fluid capacity:
Via BN:
Components
2.3L ECOBOOST MOTORCRAFT PART NUMBER | 2.7L ECOBOOST MOTORCRAFT PART NUMBER | |
Air filter element | FA-2022 | FA-2022 |
Battery | BAGM-94RH7-800 | BAGM-94RH7-800 |
Cabin air filter | FP-93 | FP-93 |
Engine oil filter | FL-910-S | FL-2062-A |
Spark plug | SP-594 | SP-594 |
Transmission fluid filter | FT-202 | FT-202 |
Windshield wiper blade (front) | WW-1703 | WW-1703 |
Windshield wiper blade (rear) | WW-801 | WW-801 |
Engine Oil
Capacity (including the oil filter) for the EcoBoost engines:
- 3L: 6.2 quarts
- 7L: 7 quarts
2.3L ECOBOOST MOTORCRAFT PART NUMBER | 2.7L ECOBOOST MOTORCRAFT PART NUMBER | |
SAE 5W-30 Synthetic Blend Motor Oil (U.S.) | WSS-M2C961-A1 | WSS-M2C961-A1 |
Extreme cold (-22.0°F) alternative: SAE 0W-30 Synthetic Blend | WSS-M2C963-A1 | WSS-M2C963-A1 |
Coolant
Capacity for the cooling systems:
- 3L w/ automatic transmission: 10.5 quarts
- 3L w/ manual transmission: 9.6 quarts
- 7L: 12.4 quarts
2.3L ECOBOOST MOTORCRAFT PART NUMBER | 2.7L ECOBOOST MOTORCRAFT PART NUMBER | |
Motorcraft® Yellow Prediluted Antifreeze/ Coolant (U.S.) | WSS-M97B57-A2 | WSS-M97B57-A2 |
Fuel Tank Capacity
The two- and four-door models’ tanks hold:
- Short wheelbase: 17.4 gallons
- Long wheelbase: 21.1 gallons
Air Conditioning
All Broncos’ AC systems hold 19.4 ounces of refrigerant.
SPECIFICATION | |
R-1234yf Refrigerant (U.S.) | WSS-M17B21-A |
Motorcraft® R-1234yf Refrigerant PAG Oil (U.S.) | WSS-M2C300-A2 |
Washer Fluid
The manual doesn’t say how much the washer fluid reservoir holds, just to fill as needed.
MOTORCRAFT PART NUMBER | |
Motorcraft® Premium Windshield Wash Concentrate with Bitterant (U.S.) | WSS-M14P19-A |
Transmission Fluid
The fluid capacity (approximate dry fill. Actual amount could vary during fluid changes):
- Manual transmission: 2.4 quarts
- Automatic transmission: 13.1 quarts
MOTORCRAFT PART NUMBER | ||
Manual | Motorcraft® Dual Clutch Transmission Fluid (U.S.) | WSS-M2C200-D2 |
Automatic | Motorcraft® MERCON® ULV Automatic Transmission Fluid (U.S.) | WSS-M2C949-A, MERCON® ULV |
Brake Fluid
Capacity: the clutch and brake systems’ quantity is listed as “Fill as required.”
MOTORCRAFT PART NUMBER | |
Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid (U.S.) | WSS-M6C65-A2 |
Transfer Case Fluid
The T-case holds:
- 4×4 with part time engagement: 1.3 quarts
- Advanced 4×4 with 4A mode: 1.6 quarts
MOTORCRAFT PART NUMBER | |
Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.) | WSS-M2C938-AMERCON® LV, |
Axle Fluid
Front axle fluid capacity:
- W/ electronic locking differential: 26.2 fluid ounces
- W/o electronic locking differential and w/o front axle disconnect: 29.2 fluid ounces
- W/o electronic locking differential and w/ front axle disconnect: 30.4 fluid ounces
- W/ electronic locking differential: 63.6 fluid ounces
- W/o electronic locking differential: 65.3 fluid ounces
MOTORCRAFT PART NUMBER | |
Motorcraft® SAE 80W-90 Premium Rear Axle Lubricant (U.S.) | WSP-M2C197-A |
Motorcraft® SAE 75W-85 Premium Synthetic Hypoid Gear Lubricant (U.S.) | WSS-M2C942-A |
