Severe Duty Steering Rack, help

Oldhippie

Big Bend
Well-Known Member
First Name
Barry
Joined
Nov 1, 2021
Threads
12
Messages
1,129
Reaction score
2,247
Location
Santa Cruz, Calif.
Vehicle(s)
BMW X1, ‘1928 model A, “23 Bronco
Your Bronco Model
Big Bend
Ok against my better judgment I purchased the severe duty steering rack and procal to install in my bronco. Being a complete computer idiot I called ford before doing anything…a couple hours on the phone and the tune and rack upgrades were loaded in the procal and the tune was installed in the bronco…I then installed the 74weld stage 1 kit in the rack and waited til my buddy had some time and empty lift to install the rack (and diff drop)…got on the lift and did the procal rack download before starting the install (wanted to turn the bronco around on the lift so started the bronco but the steering would not turn so left it as is and shut it off)…did the rack (diff drop was kinda more a pita) install without any major problems…there are no codes (never were any and did not delete any) on the procal but there is a steering assist fault message on the dash and goat modes do not work (they have come back a few times but go away right away)…ford tech can’t do anything without any codes…thinks may be a defective rack…It drives fine but don’t want to drive it with the fault message or go off road without goat modes…local dealer is small with limited computer resources in my experience…any thoughts/help would be appreciated!! Thanks!!
Sponsored



kodiakisland

Black Diamond
Well-Known Member
Joined
Jul 10, 2020
Threads
29
Messages
5,964
Reaction score
17,109
Location
Arkansas
Vehicle(s)
12 Tacoma, 18 Indian, 23 GV70
Your Bronco Model
Black Diamond
Clubs

Is your VIN supported by procal for the 3.0 steering rack? Only select models are and the rest have to be programmed through forscan.


userdude

Badlands
Well-Known Member
First Name
Jared
Joined
Feb 20, 2023
Threads
36
Messages
4,147
Reaction score
7,323
Location
Denton, TX
Vehicle(s)
2023 2dr Badsquatch
Your Bronco Model
Badlands
Clubs

@flip, do you think this would show up in that system you check sometimes?


userdude

Badlands
Well-Known Member
First Name
Jared
Joined
Feb 20, 2023
Threads
36
Messages
4,147
Reaction score
7,323
Location
Denton, TX
Vehicle(s)
2023 2dr Badsquatch
Your Bronco Model
Badlands
Clubs

I'm actually wondering if perhaps something got unplugged during the install. I had a couple fault messages after replacing a bumper and figured out I didn't push the plug all the way in.


Ducati1098

Wildtrak
Well-Known Member
Joined
Jul 14, 2020
Threads
13
Messages
4,998
Reaction score
10,364
Location
Midwest
Vehicle(s)
2022 Bronco Wildtrak, 2006 Corvette Z06, 2012 Ford Fusion
Your Bronco Model
Wildtrak
Clubs

"ford tech can’t do anything without any codes…thinks may be a defective rack"

I don't understand this. They should be able to follow a pinpoint test in the symptom chart and come to a conclusion on what's causing the issue 🤷‍♂️


Sponsored
OP
OP
Oldhippie

Oldhippie

Big Bend
Well-Known Member
First Name
Barry
Joined
Nov 1, 2021
Threads
12
Messages
1,129
Reaction score
2,247
Location
Santa Cruz, Calif.
Vehicle(s)
BMW X1, ‘1928 model A, “23 Bronco
Your Bronco Model
Big Bend
Is your VIN supported by procal for the 3.0 steering rack? Only select models are and the rest have to be programmed through forscan.
yes it is supported, thanks


Bmadda

Badlands
Well-Known Member
First Name
Brian
Joined
Jul 18, 2020
Threads
20
Messages
2,871
Reaction score
6,695
Location
Wisconsin USA
Vehicle(s)
1990 Bronco eddie bauer
Your Bronco Model
Badlands
Clubs

You are gonna need a generic scan tool, or FDRS to pull codes from the PSCM module (control module mounted in the rack). I'm fairly certain procal will only check engine codes. My 1st rack was defective. It can happen. I posted about it in the old Hoss 3.0 rack thread started by @BigMeatsBronco but good luck finding it. If you get the same codes I got likely you got a bad one. I don't remember the exact codes offhand, but I can find them if you post what error codes you are getting. Should start with "C"...wana say I got C200C

OP
OP
Oldhippie

Oldhippie

Big Bend
Well-Known Member
First Name
Barry
Joined
Nov 1, 2021
Threads
12
Messages
1,129
Reaction score
2,247
Location
Santa Cruz, Calif.
Vehicle(s)
BMW X1, ‘1928 model A, “23 Bronco
Your Bronco Model
Big Bend
I'm actually wondering if perhaps something got unplugged during the install. I had a couple fault messages after replacing a bumper and figured out I didn't push the plug all the way in.
This was also mentioned by tech/engineer I’ve be dealing with…will go back in and check plugs…

OP
OP
Oldhippie

Oldhippie

Big Bend
Well-Known Member
First Name
Barry
Joined
Nov 1, 2021
Threads
12
Messages
1,129
Reaction score
2,247
Location
Santa Cruz, Calif.
Vehicle(s)
BMW X1, ‘1928 model A, “23 Bronco
Your Bronco Model
Big Bend
"ford tech can’t do anything without any codes…thinks may be a defective rack"

I don't understand this. They should be able to follow a pinpoint test in the symptom chart and come to a conclusion on what's causing the issue 🤷‍♂️
I am completely with you on this but nothing is happening from them…

OP
OP
Oldhippie

Oldhippie

Big Bend
Well-Known Member
First Name
Barry
Joined
Nov 1, 2021
Threads
12
Messages
1,129
Reaction score
2,247
Location
Santa Cruz, Calif.
Vehicle(s)
BMW X1, ‘1928 model A, “23 Bronco
Your Bronco Model
Big Bend
You are gonna need a generic scan tool, or FDRS to pull codes from the PSCM module (control module mounted in the rack). I'm fairly certain procal will only check engine codes. My 1st rack was defective. It can happen. I posted about it in the old Hoss 3.0 rack thread started by @BigMeatsBronco but good luck finding it. If you get the same codes I got likely you got a bad one. I don't remember the exact codes offhand, but I can find them if you post what error codes you are getting. Should start with "C"...wana say I got C200C
I have nothing but the procal so will need to find someone with tools to help…thank you…place to look…


Sponsored

Ducati1098

Wildtrak
Well-Known Member
Joined
Jul 14, 2020
Threads
13
Messages
4,998
Reaction score
10,364
Location
Midwest
Vehicle(s)
2022 Bronco Wildtrak, 2006 Corvette Z06, 2012 Ford Fusion
Your Bronco Model
Wildtrak
Clubs

OP
OP
Oldhippie

Oldhippie

Big Bend
Well-Known Member
First Name
Barry
Joined
Nov 1, 2021
Threads
12
Messages
1,129
Reaction score
2,247
Location
Santa Cruz, Calif.
Vehicle(s)
BMW X1, ‘1928 model A, “23 Bronco
Your Bronco Model
Big Bend
Ductati1098 is the man! After having me sign into fordpass (never understood any need for it) he was able to pull a code
PSCM U2100 : 00 : 2F Initial Comfigutation Not Complete
seems like something in the reprogramming did not work??
don’t know how to fix it? But have a direction…


mpeugeot

Outer Banks
Well-Known Member
First Name
Mark
Joined
May 14, 2021
Threads
21
Messages
8,338
Reaction score
16,611
Location
Texas
Vehicle(s)
97 Ferrari F355, 11 Ford F-150, 21 OBX 2D
Your Bronco Model
Outer Banks
Ductati1098 is the man! After having me sign into fordpass (never understood any need for it) he was able to pull a code
PSCM U2100 : 00 : 2F Initial Comfigutation Not Complete
seems like something in the reprogramming did not work??
don’t know how to fix it? But have a direction…
Fire up FDRS and do the initial Calibration under the PSCM, and that will fix it.

@Ford Motor Company, you missed your moment.
