Transfer Case Manufacturer?

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
  • Thread starter
  • Banned
  • #1
Anyone know the make/model of t-case(s) available? New Process?
Sponsored


OP
OP

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
  • Thread starter
  • Banned
  • #4
Yeah, figured Borg-Warner or New Venture Gear/New Process, but wanted to know for sure. The Super Duty uses a NVG/NP and I was wondering if it was related to that, but Borg certainly could be the answer.

Maybe anal, but I'd like to know, and know the internals (I've rebuilt t-cases in the past and want to know what I'm buying).

Anyone know for sure?


VoltageDrop

Base
Well-Known Member
First Name
Eric
Joined
Jul 22, 2020
Threads
14
Messages
1,414
Reaction score
3,952
Location
Fidalgo Island, WA
Vehicle(s)
23, 69 Bronco
Your Bronco Model
Base
Clubs

Yeah, figured Borg-Warner or New Venture Gear/New Process, but wanted to know for sure. The Super Duty uses a NVG/NP and I was wondering if it was related to that, but Borg certainly could be the answer.

Maybe anal, but I'd like to know, and know the internals (I've rebuilt t-cases in the past and want to know what I'm buying).

Anyone know for sure?
I'm curious too, especially what type of clutch the 4A version uses. Maybe same as F150? Looking at pictures, I'm wondering if Ford itself is making them. I only see the Ford logo cast into the case.

F150 part number: gl347a195ba


Sponsored
OP
OP

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
  • Thread starter
  • Banned
  • #7
I don't like the idea of a clutch, but wonder of it's a split 60/40 or something


HoosierDaddy

Badlands
Well-Known Member
First Name
Eric
Joined
Mar 6, 2016
Threads
37
Messages
5,364
Reaction score
13,670
Location
Indiana
Vehicle(s)
68&69 Broncos, 21 AMB Base 2dr, 23 VB BL 4dr
Your Bronco Model
Badlands
Clubs

I'm curious too, especially what type of clutch the 4A version uses. Maybe same as F150? Looking at pictures, I'm wondering if Ford itself is making them. I only see the Ford logo cast into the case.

F150 part number: gl347a195ba
Judging by the 10r60 tranny info that dropped recently....maybe similar to the Exploders? LOL

OP
OP

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
  • Thread starter
  • Banned
  • #9
Hope not, but...

OP
OP

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
Actually, thinking more about it, NVG/BP usually have a 2.72:1 so its probabaly so.ething else.


dgorsett

Big Bend
Well-Known Member
Joined
Apr 3, 2019
Threads
24
Messages
3,707
Reaction score
7,482
Location
colorado
Vehicle(s)
F250, Mustang, Explorer
Your Bronco Model
Big Bend
Clubs


Sponsored

dgorsett

Big Bend
Well-Known Member
Joined
Apr 3, 2019
Threads
24
Messages
3,707
Reaction score
7,482
Location
colorado
Vehicle(s)
F250, Mustang, Explorer
Your Bronco Model
Big Bend
Clubs

Actually, thinking more about it, NVG/BP usually have a 2.72:1 so its probabaly so.ething else.
Regular part time TC is 2.72, Advanced is 3.something.

OP
OP

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
Oh, then it probably is a NVG/NP. Thanks.


John Bronco_ I am here

Badlands
Well-Known Member
First Name
John
Joined
Nov 6, 2020
Threads
8
Messages
421
Reaction score
1,034
Location
North America
Website
johnbronco.com
Vehicle(s)
'66 Bronco, '08 JK
Your Bronco Model
Badlands
I don't like the idea of a clutch, but wonder of it's a split 60/40 or something
The split is 50/50. The system is an "automatic four-wheel-drive", this is in contrast to an all-wheel-drive system where some systems can vary where torque is applied. The clutch in the transfer case is either fully engaged or fully disengaged and there are no hub or drive line disconnects besides the transfer case. The system is "automatic" because the PCM controls the clutch and can engage/disengage it in milliseconds when in 4A and slip happens. When in 4H/L 12 volts will be applied to the clutch all the time making the transfer case act like any other part-time case.

OP
OP

AcesandEights

Banned
Badlands
Banned
Banned
First Name
Ace!
Joined
Nov 19, 2020
Threads
16
Messages
1,229
Reaction score
2,488
Location
Oregon
Vehicle(s)
DR650
Your Bronco Model
Badlands
With that kind of info, do you know the manufacturer?

I don't like the idea of clutches, because like the Bronco Sport or other "Intelligent" 4WD systems of Ford, they overheat in sand and have to be cooled. I'd rather have a mechanical split.
