Hooking up boom blaster to aux switch

[Ironiguana]

Has anybody out there done this? I am guessing red to full time power (is there another connection point for this besides battery itself?), black to ground, Yellow to aux switch wire to initiate horn. Any help would be appreciated.

Sponsored



[IDyeti]

I went with a 1A fused to the battery, used the small gauge empty post. Yellow to the aux 6 wire. Ground to a one of the ground bolts nearby.

Alternatively you could burn up two aux switches red to say aux 5 and yellow to say aux 6. Pro: horn is only has power with red wire (aux 5 in this situation) is engaged. Then you trigger the sound by flipping aux 6 on then off. Con: abuse of aux switches.

The sound is played when power is removed from the yellow wire, flipping the aux siwtch to off position.

Enjoy the chessy humor, my wife and I do. Its hilarous!



[Ironiguana]

Got it to work!



[ColonelAngus]

I think your Bronco has a squeaky belt....
