Last year Flip posted a shop manual picture of the rear window schmatics.
This showed that the bolts must be discarded and not re-used.. I can not now find that. Can one of you help and old man? @flip, is it possible to re-post this info?
NOTE: Removal steps in this procedure may contain installation details.
Open the tailgate.
Open the liftgate window glass.
NOTE: Liftgate shown closed for clarity. NOTE: Left hand (LH) shown, right hand (RH) similar.
On both sides.
Disconnect the heated rear window element electrical connectors.
Remove the rear window wiper motor cover.
Use the General Equipment: Interior Trim Remover
NOTE: Liftgate shown closed for clarity.
Disconnect the rear window wiper motor electrical connector.
Release the retainers and position the rear window wiper motor wiring harness aside.
NOTE: Liftgate shown closed for clarity.
Release the rear window wiper motor wiring harness support and position aside.
NOTE: Liftgate shown closed for clarity.
Disconnect the rear window washer hose.
NOTE: Liftgate shown closed for clarity.
On both sides.
Release the clips and disconnect the rear window glass liftgate strut.
On both sides.
Release the rear window glass liftgate strut clip.
On both sides.
Disconnect the rear window glass liftgate strut.
Release the liftgate window glass hinge trim covers.
Remove the bolts and the liftgate window glass. Torque: 97 lb.in (11 Nm)
NOTE: This step is only necessary when installing a new component.
Remove the liftgate window glass hinge trim covers.
NOTE: This step is only necessary when installing a new component.
Remove the rear window wiper motor.
Refer to: Rear Window Wiper Motor (501-16 Wipers and Washers, Removal and Installation).
NOTE: This step is only necessary when installing a new component.
Remove the rear window washer jet.
Refer to: Rear Window Washer Jet (501-16 Wipers and Washers, Removal and Installation).
NOTE: This step is only necessary when installing a new component.
Remove the rear window wiper motor pivot shaft grommet.
NOTE: This step is only necessary when installing a new component.
Remove the rear window glass weather strip end caps.
NOTE: Removal steps in this procedure may contain installation details.
Open the tailgate.
Open the liftgate window glass.
NOTE: Liftgate shown closed for clarity. NOTE: Left hand (LH) shown, right hand (RH) similar.
On both sides.
Disconnect the heated rear window element electrical connectors.
Remove the rear window wiper motor cover.
Use the General Equipment: Interior Trim Remover
NOTE: Liftgate shown closed for clarity.
Disconnect the rear window wiper motor electrical connector.
Release the retainers and position the rear window wiper motor wiring harness aside.
NOTE: Liftgate shown closed for clarity.
Release the rear window wiper motor wiring harness support and position aside.
NOTE: Liftgate shown closed for clarity.
Disconnect the rear window washer hose.
NOTE: Liftgate shown closed for clarity.
On both sides.
Release the clips and disconnect the rear window glass liftgate strut.
On both sides.
Release the rear window glass liftgate strut clip.
On both sides.
Disconnect the rear window glass liftgate strut.
Release the liftgate window glass hinge trim covers.
Remove the bolts and the liftgate window glass. Torque: 97 lb.in (11 Nm)
NOTE: This step is only necessary when installing a new component.
Remove the liftgate window glass hinge trim covers.
NOTE: This step is only necessary when installing a new component.
Remove the rear window wiper motor.
Refer to: Rear Window Wiper Motor (501-16 Wipers and Washers, Removal and Installation).
NOTE: This step is only necessary when installing a new component.
Remove the rear window washer jet.
Refer to: Rear Window Washer Jet (501-16 Wipers and Washers, Removal and Installation).
NOTE: This step is only necessary when installing a new component.
Remove the rear window wiper motor pivot shaft grommet.
NOTE: This step is only necessary when installing a new component.
Remove the rear window glass weather strip end caps.
