Wireless charging pad DIY install hack

[billybong420]

Wonder how long until people do write ups on putting in the factory wireless charger. Should bolt right in (there’s a blank cover plate in place on vehicles not equipped) just would take some wiring knowledge.

so i have been working on this ,
LL1Z-19J235-A is the charging pad (for my 2 door stick)
then because the connector is not available seperately , i needed to purchase a new harness...... but on the bronco its part of the main dash harness, so i did a "where used" search on the pad and found out it was used in an f-150 so i ordered that console harness, JL1Z-14A318-K, Of course then went into the shop manual and it explained that it would need to shut off during the key search as it may interfere. I AM LITERALLY 3 HOURS OF BOOK WORK ON THIS AND THIS G/D GENIUS FIGURED OUT A SIMPLER, MORE PRAGMATIC SOLUTION BY SLIPPING A CHARGER UNDER THE F'NNN MATT. I BOW TO YOU SIR , I BOW TO YOU

Sponsored



[Rosanna]

so i have been working on this ,
LL1Z-19J235-A is the charging pad (for my 2 door stick)
then because the connector is not available seperately , i needed to purchase a new harness...... but on the bronco its part of the main dash harness, so i did a "where used" search on the pad and found out it was used in an f-150 so i ordered that console harness, JL1Z-14A318-K, Of course then went into the shop manual and it explained that it would need to shut off during the key search as it may interfere. I AM LITERALLY 3 HOURS OF BOOK WORK ON THIS AND THIS G/D GENIUS FIGURED OUT A SIMPLER, MORE PRAGMATIC SOLUTION BY SLIPPING A CHARGER UNDER THE F'NNN MATT. I BOW TO YOU SIR , I BOW TO YOU

Thank you for the praise! I’m not a genius or a sir, probably why I figured it out first



[billybong420]

Thank you for the praise! I’m not a genius or a sir, probably why I figured it out first

haha, thank you for the correction, forgive me, its usually a sausage fest up in this place. and i still bow to you!!!!



[Rosanna]

haha, thank you for the correction, forgive me, its usually a sausage fest up in this place. and i still bow to you!!!!

No worries I’m quite aware I’m in a small minority here lol. I’m not knowledgeable with engines or electrical systems hence the easy work around!



[billybong420]

No worries I’m quite aware I’m in a small minority here lol. I’m not knowledgeable with engines or electrical systems hence the easy work around!

I will let you in on a little secret....NO ONE HERE IS



[Rosanna]

I will let you in on a little secret....NO ONE HERE IS

I’ll tell you a secret my husband is a mechanical engineer. He fixes his cars constantly but I wanna try to take care of mine as much as I can.



[MaverickMan]

Anyone have a link to a wireless charger with a the shorter cord? Mine all have 3-5 feet of cable that isn't ideal for this application.

Cut and splice?



[MaverickMan]

I will let you in on a little secret....NO ONE HERE IS

Knowledge and willingness to try are two different things, with two different safety ratings



[MaverickMan]

so i have been working on this ,
LL1Z-19J235-A is the charging pad (for my 2 door stick)
then because the connector is not available seperately , i needed to purchase a new harness...... but on the bronco its part of the main dash harness, so i did a "where used" search on the pad and found out it was used in an f-150 so i ordered that console harness, JL1Z-14A318-K, Of course then went into the shop manual and it explained that it would need to shut off during the key search as it may interfere. I AM LITERALLY 3 HOURS OF BOOK WORK ON THIS AND THIS G/D GENIUS FIGURED OUT A SIMPLER, MORE PRAGMATIC SOLUTION BY SLIPPING A CHARGER UNDER THE F'NNN MATT. I BOW TO YOU SIR , I BOW TO YOU

Any thoughts on adding the charger into one of the aux switches? Just a thought.



[Binky]

I found this for F150, but I don't think it will fit our Broncos. Would be cool if someone made one to fit.

https://www.amazon.com/FIILINES-Wireless-Charger-2017-2020-Charging/dp/B08FBSX3JZ



[billybong420]

Honestly, after driving our mannequin for a while, the only reason i was going wireless on the charger was the wireless carplay, but i find just plugging it in to my cable works better.



[treadlightly]

@Rosanna, what has your experience been with the wireless charger? Specifically, do you know if it will keep a phone charged (or better yet, increase its charge) while connected to something like Android Auto or Apple Car Play wirelessly?



[Rosanna]

@Rosanna, what has your experience been with the wireless charger? Specifically, do you know if it will keep a phone charged (or better yet, increase its charge) while connected to something like Android Auto or Apple Car Play wirelessly?

I’ll let you know I just installed it yesterday. Ive had the charger for some time and it works great. I never had apple car play so not sure how it will effect the charger. I can follow up later.



[95Bravo]

Wow, great idea...sounds so familiar?!! :
https://www.bronco6g.com/forum/threads/wireless-charger-fits-auto-console.21319/



[Rosanna]

Wow, great idea...sounds so familiar?!! :
https://www.bronco6g.com/forum/threads/wireless-charger-fits-auto-console.21319/

Haha clearly I didn’t search threads for this
