Flat tow wiring diagram behind RV

[Deerslayer]

Can someone tell me what wires you used to at the taillights to wire in the 2 diodes to flat tow?
I have a 2022 badlands 2.3L manual with led lights.

Sponsored



[TXscooterguy]

It might be easier to install a "no splice" 4-pin harness made specifically for your model. The connector pins are different on the LED and halogen taillights.



[Happy]

Is this it?



[68 galaxie]

Curt lights have a plug and play set of wiring to flat tow 2021 and 2022



[68 galaxie]

Can someone tell me what wires you used to at the taillights to wire in the 2 diodes to flat tow?
I have a 2022 badlands 2.3L manual with led lights.

Check the Curt wiring harness it’s plug in to flat tow come with great instructions



[68 galaxie]

Can someone tell me what wires you used to at the taillights to wire in the 2 diodes to flat tow?
I have a 2022 badlands 2.3L manual with led lights.

This was easy to install great instructions plus a video. If you cut the 4way plug off and run a hot and ground to a 7way plug it will charge your battery as you tow your bronco.



[Deerslayer]

This was easy to install great instructions plus a video. If you cut the 4way plug off and run a hot and ground to a 7way plug it will charge your battery as you tow your bronco.

Isn’t this for the non-led lights though? The led lights have a different wiring system.



[Lifeliberty]

Isn’t this for the non-led lights though? The led lights have a different wiring system.

Curt has 2 options, led and non led harnesses now, get what fits you

https://www.etrailer.com/t1-2022_Ford_Bronco.htm



[Deerslayer]

Curt has 2 options, led and non led harnesses now, get what fits you

What’s the part number and where did you get it at?



[Lifeliberty]

What’s the part number and where did you get it at?

Just Google it

https://www.etrailer.com/t1-2022_Ford_Bronco.htm

Or Napa



[Lifeliberty]

https://www.curtmfg.com/part/56468 with LED

Napa price https://www.napaonline.com/accessor...Vvlf-l06gOaNhylmoBoC4uUQAvD_BwE&gclsrc=aw.ds&

Without led https://www.curtmfg.com/part/56471

Thread with all info about curt wirng and led/non led https://www.bronco6g.com/forum/thre...-trailer-wiring-harness-out-for-bronco.25164/



[Deerslayer]

I am not trying to wire up a trailer I am trying to set up the lights to work off of our super C RV. Most of these kits are for setting up trailer lights.



[dgorsett]

I am not trying to wire up a trailer I am trying to set up the lights to work off of our super C RV. Most of these kits are for setting up trailer lights.

Yes, I think Lifeliberty is giving you the ones for trailer towing. For flat tow the numbers Curt nos are 58992 and 58996 w and w/o LED respectively.
Here's Curts site All Products for 2021 Ford Bronco (curtmfg.com)

I found 58996 at Carid for $65

I haven't bought one yet, I used the Curt kit for the trailer tow hitch and wiring but am using stand alone lights for towed for now.



[68 galaxie]

Yes, I think Lifeliberty is giving you the ones for trailer towing. For flat tow the numbers Curt nos are 58992 and 58996 w and w/o LED respectively.
Here's Curts site All Products for 2021 Ford Bronco (curtmfg.com)

I found 58996 at Carid for $65

I haven't bought one yet, I used the Curt kit for the trailer tow hitch and wiring but am using stand alone lights for towed for now.

carid wants 35$ to ship



[Deerslayer]

This is for a 2021. Doesn’t say it’s compatible with the 22’ w/led lights.
has anyone wired in the diodes for the led lights?
