It looks like a saw.Nice clean cuts! Did you use a grinder or saw.
Looking at the piece that was cutoff you can see marks that he definitely used a sawzall. He probably grinded the frame a little bit with a flapper wheel before painting.Nice clean cuts! Did you use a grinder or saw.
but they are not triangulatedBruno if you're that worried you can model it in Autodesk Fusion and then stress it.
But fun fact: plate isn't always the the strongest. Placing stratigic holes not only reduces overall weight but also allows for stressors to be placed from multiple forces and directions.
I only work in 3DMax & Autocad, which doesnt do stress analysis, it only makes beautiful things. This is something IMO that doesnt need to be beautiful. It needs to be designed with function in mind first. Yes, including holes for access - but it looks like it is over-stylised for no apparent reason and appears to be potentially weaker becasue of that.I'm going out on a limb and suggest that Bruno does't have Autodesk let alone the capacity to understand finite stress analysis.
1) Price is definitely based on opinion. I personally think it’s pretty close to fair. There is a frame horn brace and crash bar delete that you can buy separately and they are pretty close to this price together. This is a all-in-one complete kit.Things that jump out to me that folks might want to consider;
1) The cost! 500 hundy is a lot for this kit
2) This most definitely voids the frame warranty, this may not be any concern for off-road users. On-road is different as the crash bars are there for a reason - federal crash standards so
user beware!
3)Looking thru the instructions there are no torque specs - when tightening the bolts running
thru the frame rails, overtightening the hardware could start the collapse/deformation of the horn. My gut says if this kit had an engineers stamp on it there would be torque specs. Early collapse will change the crash characteristics. Maybe a nothin burger - maybe not
I'm not trying to dump on this kit - it's nice to have vendors working on solutions, but some do carry more risk than others. Whenever you modify the frame and alter body mounts, there is risk.
I like the idea of the kit but would definitely be asking questions from the manufacturer before I order
Bruno, you seem to be taking a personal dislike for this product. I'm curious, Where did you receive your mechanical engineering degree?If it wasn't full of holes, it would be stronger
Reciprocating saw with a metal blade. Used a flap disk grinder to smooth out.Nice clean cuts! Did you use a grinder or saw.
Bruno they don't have to be triangles (I'm assuming that's what you mean by "triangulated" in order to meet the requirements. In fact sharp points are locations of stress points, so even if they were triangle shaped the points would all need to be roundedbut they are not triangulated
thanks for the education - yes obv rounded points. I guess I wish the whole thing was more filled in - in general. nSeems like its covered with big openings for style only and you barely see this. my gut tells me it would perform better if it was as solid as possible minus the access holes. Im not suggesting "plate steel" . I also think all those welds will just snap as opposed to deform, I think you could breakform more of this if a small / scaleable brake was used. I think I see alot of performance limitations based on style choices and fabrication capabilitiesBruno they don't have to be triangles (I'm assuming that's what you mean by "triangulated" in order to meet the requirements. In fact sharp points are locations of stress points, so even if they were triangle shaped the points would all need to be rounded
to do so you will also need the material strength of the steel ford usesProbably not, but he can learn how to on Brilliant. And even if he doesn't watch some lectures on it, there's always hope that whoever reads this exchange learns a bit of engineering.
