#1 - Winch relay trigger
#2 - Ditch lights
#3 - Bumper fog lights
#4 - Currently open
#5 - Currently open
#6 - Whinny horn

Sponsored



[dejones64]

1. Rough Country Osram ditch (4)
2. DD 30" light bar
3. DD White Spots
4. DD White Fogs
5. DD Yellow Fogs
6. Amber backlighting in the DD lights 3-5

1-4 is because I hit a deer and want to avoid that as much as possible again.



[HighVelocity]

Make sure you add additional switches, so you can have switches to turn on your switches.



[routhless]

I'm sure I'll change this up a bit later on but currently mine is:

1. rear chase bar
2. front light bar
3. ditch lights
4, 5 and 6 currently work different functions of my fog lights (off-road, back light only, fogs only)



[SubmarineNuke]

Switch 1: KC Light bar
Switch 2: KC Pod lights
Switch 6: Rigid wheel well lights and backlight for light pods



[Bruno]

I'm sure I'll change this up a bit later on but currently mine is:

1. rear chase bar
2. front light bar
3. ditch lights
4, 5 and 6 currently work different functions of my fog lights (off-road, back light only, fogs only)

Did you wire your 3 Running lights (in the grill) directly into the existing running lights? So they are always on or at least at night?
Do you have a how-to on that (if you did)
TY!!



[helifino16]

These are a very nice thing to have:
Aux1 - Air Horn
Aux2 - A-pillar Lights
Aux3 - Bumper mounted light bar
Aux4 - Smoke screen
Aux5 - Oracle Grill Letters
Aux6 - Traditional Coffee Maker

I had to switch out the Passenger Ejector seat, it didn't work most of the time.



[TCoupe]

1. reserved for future winch
2. open
3. open
4. Oracle "Bronco" lighted letters on front grille
5. White Fog lights (Mabett Raptor style)
6. Amger Fog lights (Mabett Raptor style) - great for snow as amber adds color to the snow banks

No idea what to put on 2 and 3!



[Johnny Mo]

1) Raptor 2nd set factory fogs
2) Open
3) KC Flex Era 4 A-pillar lights
4) KC Cyclone Rock Lights
5) ARB Compressor/Air Horn Relay interrupt
6) KC Flex Era 4 backlighting

Will have a separate KC single cyclone underhood - using a magnetic reed switch - just haven't gotten around to it. May use the 2nd KC from that kit as a rear cargo light under my DIY shelf.



[mlugb6ro]

1 open
2 front bar light in-between bumper and grill
3 under body cameras
4 left ditch light hidden in the wheel well
5 right ditch light hidden in the wheel well
6 rear lights under spare mounted on the trailer hitch

All cheap amazon stuff, mostly unnoticeable, just wanted to use the auxiliary switches, but they are useful sometimes.



[NoloBronco]

Did you wire your 3 Running lights (in the grill) directly into the existing running lights? So they are always on or at least at night?
Do you have a how-to on that (if you did)
TY!!

You can tap into the marker lights as well. Then they only come on when it is dark or the head lights are switched on.



[lil_mule_4x4]

Thank you @lil_mule_4x4
I had the winch and air compressor wired up to the Aux switches at one time but took them back to the original method of switches to reserve my Aux switches.

@NoloBronco - That was part of why I began this thread!



[Bruno]

You can tap into the marker lights as well. Then they only come on when it is dark or the head lights are switched on.

Cool, do u know the best place to do that?
And what the volts & amps are of the markers so I can check if my LEDs are compatible



[NoloBronco]

@NoloBronco - That was part of why I began this thread!

Yeah, I have changed it up more than I care to mention. Had to add wire to my Aux wires.



[NoloBronco]

Cool, do u know the best place to do that?
And what the volts & amps are of the markers so I can check if my LEDs are compatible

I tapped into the wiring harness behind the head light. Had to remove the headlight to access. I honestly do not remember the color of wire. I believe it was green but I would confirm. I figured it out on the forum and can not find the thread now to send to you. As for the amps, I do not have a clue but would assume you are safe as I am running the raptor/marker lights in the grill, back lights for BD LP6’s and LP4’s and a light that is build into my winch all off of this tap.
